Line Scan Lenses Features :
* Support 8K~12k line scann camera 5μm
* Max image 66mm
* Max aperture F4.5
* Magnification 0.2x~1.24x
* Super low distortion
Click below model to view datasheet :
|
Model
型号
|
Focal Length
|
Mag.
倍率
|
Fomat
靶面
|
Apert.
光圈
|
W.Dist
工作距
|
Flange Distance
|
Mount
接口
|
Resolution
解像力
|
|
SLS1202V
|
116mm
|
0.2X
|
φ66
|
f4.5
|
652.4
|
122.8
|
V
|
12K
|
|
SLS1203V
|
116mm
|
0.33X
|
φ66
|
f4.5
|
415.1
|
134.9
|
V
|
12K
|
|
SLS1205V
|
116mm
|
0.5X
|
φ66
|
f4.5
|
291.7
|
149.6
|
V
|
12K
|
|
SLS1207V
|
116mm
|
0.75X
|
φ66
|
f4.5
|
209..8
|
170.3
|
V
|
12K
|
|
SLS1208V
|
116mm
|
0.806X
|
φ66
|
f4.5
|
203.8
|
181.2
|
V
|
12K
|
|
SLS1210V
|
116mm
|
1X
|
φ66
|
f4.5
|
164.2
|
186.7
|
V
|
12K
|
|
SLS1212V
|
116mm
|
1.24X
|
φ66
|
f4.5
|
149.9
|
232.2
|
V
|
12K
|
|
