CURRENT:HOME > PRODUCTS - 1.1" 20 Megapixel Lenses - S11MV1222-20M ( 12mm ) 1.1" VIP
Product name:S11MV1222-20M ( 12mm ) 1.1" VIP
Product description:


12mm 1.1" 20MP Machine Vision FA <0.5% Low Distortion Industrial Face Recognition 8K Camera Megapixel Lenses

  • High resolution :       20 megapixel cover all 8K & 4K
  • Large format:           1.1" size covering 1", 3/4, 2/3", 1/1.8", 1/2" camera
  • Low distortion :        <0.5% low distortion use machine vision
  • Magnification :         0.0087x ~ 0.003x ( 100mm ~ 5000mm )
  • Application :              Automation, machine vision, medical, life science, ITS, SMT, AOI


Model

S11MV1222-20M

Resolution

20 Megapixel

Format  (inch)

1.1"

Focal Length  (mm)

12mm

B.F.L (mm )

12.9mm

Aperture  (Close)

F2.2 Manual Iris

Angle of View (°)

1.1"

72*61*47.5

1"

67*56*43.5

2/3"

49*40*30.5

M.O.D  (m)

0.1

Distortion

<0.5%

Size

Φ44*74

Mount

C

Weight  (g)

225
